DC V | 6.000/60.00/600.0/1000V (自动量程) ±0.5%rdg ±3dgt (6/60/600V) ±0.8%rdg ±3dgt (1000V) |
---|---|
DC mV | 600.0mV ±1.5%rdg ±3dgt |
直流钳形传感器 | 60.00/200.0A (自动量程) ±1.5%rdg ±3dgt + 传感器精确度 |
AC V | 6.000/60.00/600.0/1000V (自动量程) ±1.0%rdg ±3dgt [40 - 500Hz] (6/60/600V) ±1.3%rdg ±3dgt [40 - 500Hz] (1000V) |
AC mV | 600.0mV ±2.0%rdg ±3dgt [40 - 500Hz] |
交流钳形传感器 | 60.00/200.0A (自动量程) ±2.0%rdg ±3dgt + 传感器精确度 [40 - 500Hz] |
Ω | 600.0Ω/6.000/60.00/600.0kΩ/6.000/40.00MΩ (自动量程) ±0.5%rdg ±4dgt (600Ω) ±0.5%rdg ±2dgt (6/60/600kΩ/6MΩ) ±1.5%rdg ±3dgt (40MΩ) |
导通蜂鸣 | 600Ω (低于90Ω蜂鸣器鸣叫) |
二极管测试 | 开环电压: < 3.0V |
电容测试 | 60.00/600.0nF/6.000/60.00/600.0/1000μF ±2.0%rdg ±5dgt (60/600nF) ±5.0%rdg ±5dgt (6/60/600/1000μF) |
频率 | 99.99/999.9Hz/9.999/99.99kHz ±0.1%rdg ±3dgt |
DUTY | 10.0 - 90.0% ±1.0%rdg ±3dgt [50/60Hz] |
安全规格 | IEC 61010-1 CAT IV 300V / CAT III 600V / CAT II 1000V IEC 61010-2-033, IEC 61010-031, IEC 61326-2-2 (EMC), EN 50581 (RoHS) |
电池 | R03 (1.5V) × 2 |
外形尺寸 | 155(L) × 75(W) × 40(D)mm |
重量 | 250g Approx. (含电池) |
附件 | 翼型支架 7066A (测试线) R03 × 2, 使用说明书 |
可选件 | 7234 (鳄鱼夹测试线) 8161 (AC 钳形传感器) 8115 (AC/DC 钳形传感器) 9189 (磁性挂钩) |
